FRP WALL SUPPORT EXT —
FIBERGLASS RANGE LADDER
FRP extension ladder with non-conductive fiberglass rails for electrical maintenance at height. ERDA certified with 7-layer construction, adjustable length, and anti-slip rubber feet. The choice of utility companies across India.
ELECTRICAL
SAFETY LADDER
The FRP Wall Support Extension is a fiberglass range ladder designed specifically for working around electricity. Non-conductive FRP side rails with ERDA certification make it the safest choice for electrical maintenance, substation work, and panel servicing.
Maximum safety with 7-layer FRP construction that won't dent or shatter. Twin handrails provide stability while climbing, and the safety chain prevents accidental downfall. Slip-resistant steps and anti-skid rubber shoes complete the safety package.
Electrical Maintenance
Non-conductive FRP side rails for safe work around live electrical panels, substations, and transformers.
Industrial Facilities
Heavy-duty platform for maintenance tasks where maximum durability and chemical resistance are required.
Technical Specifications
description Download Full PDF Specs| Parameters | FRP2 Tread | FRP4 Tread | FRP6 Tread | FRP8 Tread |
|---|---|---|---|---|
| Ladder Height (Closed) | 1540mm | 2040mm | 2540mm | 3040mm |
| Max Standing Height | 480mm | 945mm | 1415mm | 1890mm |
| Weight | 13.5kg | 15.8kg | 17.5kg | 19.2kg |
| L x B Dimensions | 870x505mm | 1360x570mm | 1560x640mm | 1760x710mm |
| Maximum Reach | 1980mm | 2445mm | 2915mm | 3390mm |
Non-Conductive FRP
ERDA-certified fiberglass side rails — the gold standard for electrical safety ladder compliance.
Maximum Strength
7-layer FRP construction won't dent, shatter, or corrode — outlasts metal alternatives.
High-Visibility Design
Yellow FRP construction visible in low-light environments — improving site safety awareness.
Safety Chain
Anti-downfall safety chain prevents accidental folding while worker is on the ladder.
Resource Center
SECURE YOUR
QUOTATION
Connect with our technical consultants to design a modular system tailored for your specific site conditions and load requirements.
Deployment Excellence
Standard issue at BSES and Tata Power for all electrical maintenance — zero incidents across 10,000+ deployments.
Approved by Electrical Research and Development Association for use around live electrical equipment.
